Máy thở Respironics V60-Phillips
- Tải Báo giá - Tài liệu
- Giới thiệu
- Thông số kĩ thuật
- Cấu hình
- Phụ kiện
- Nhận xét
- Sản phẩm cùng phân khúc giá
Simplicity and versatility for sub-acute ventilation
Support many needs with a single ventilator
The Trilogy 202 is both a volume-control and pressure-control ventilator for invasive and noninvasive ventilation. The versatile breath delivery and setup options free you from burdensome equipment exchanges, providing greater continuity of care for your patients. Because the Trilogy 202 has the unique ability to compensate for leaks in both pressure and volume control modes, using simpler passive circuits may support significant time and cost savings. With one simple setting change, the Trilogy 202 supports either active or passive exhalation breathing circuits to accommodate changes in circuit preference.
Intra-hospital transport
The Trilogy 202 allows freedom of movement. With a 3-hour internal battery and optional 3-hour detachable battery, you’ll have sufficient power for intra-hospital transports – with plenty of time for any delays or detours. It weighs only 5.6 kg and has an integrated carrying handle for safe and convenient handling during intra-hospital transports.
Hospital to home transition
In addition to sharing a common user interface, all home and hospital Trilogy ventilators offer identical ventilation modes and breathing circuit configurations.
Now your home-bound patients will receive the same finely tuned ventilatory support they received in the hospital. Furthermore, stored data from the home or the hospital can be downloaded for review and evaluated for meaningful trends.
Synchrony
The Auto-Trak algorithm improves patient-ventilator synchrony by adjusting to changing breathing patterns and dynamic leaks. The auto-adaptive triggering, cycling, and leak adjustments may help reduce the time clinicians spend adjusting thresholds and re-fitting masks.
Leak compensated volume modes
Trilogy 202 offers all the conventional volume-control modes: AC, SIMV (with or without PS), and CV. The Trilogy 202 has the unique ability to compensate for leaks in a volume control mode. This means more consistent tidal volume delivery even during NIV or when cuff leaks are present.
Support many needs with a single ventilator
The Trilogy 202 is both a volume-control and pressure-control ventilator for invasive and noninvasive ventilation. The versatile breath delivery and setup options free you from burdensome equipment exchanges, providing greater continuity of care for your patients. Because the Trilogy 202 has the unique ability to compensate for leaks in both pressure and volume control modes, using simpler passive circuits may support significant time and cost savings. With one simple setting change, the Trilogy 202 supports either active or passive exhalation breathing circuits to accommodate changes in circuit preference.
Intra-hospital transport
The Trilogy 202 allows freedom of movement. With a 3-hour internal battery and optional 3-hour detachable battery, you’ll have sufficient power for intra-hospital transports – with plenty of time for any delays or detours. It weighs only 5.6 kg and has an integrated carrying handle for safe and convenient handling during intra-hospital transports.
Hospital to home transition
In addition to sharing a common user interface, all home and hospital Trilogy ventilators offer identical ventilation modes and breathing circuit configurations.
Now your home-bound patients will receive the same finely tuned ventilatory support they received in the hospital. Furthermore, stored data from the home or the hospital can be downloaded for review and evaluated for meaningful trends.
Synchrony
The Auto-Trak algorithm improves patient-ventilator synchrony by adjusting to changing breathing patterns and dynamic leaks. The auto-adaptive triggering, cycling, and leak adjustments may help reduce the time clinicians spend adjusting thresholds and re-fitting masks.
Leak compensated volume modes
Trilogy 202 offers all the conventional volume-control modes: AC, SIMV (with or without PS), and CV. The Trilogy 202 has the unique ability to compensate for leaks in a volume control mode. This means more consistent tidal volume delivery even during NIV or when cuff leaks are present.
Respironics V60
| Patient types | |
| Adult | |
| Pediatric | ≥ 20 kg |
| Modes | |
| CPAP - Continuous positive airway pressure | |
| S/T - Spontaneous with timed backup | |
| PCV - Pressure control ventilation | |
| AVAPS - Average volume assured pressure support (optional) | |
| PPV - Proportional pressure ventilation (optional) |
| Settings | |
| C-Flex | Off, 1 to 3 |
| CPAP | 4 to 25 cm H2O |
| EPAP | 4 to 25 cm H2O |
| IPAP | 4 to 40 cm H2O |
| I-time (inspiratory time) | 0.30 to 3.00 sec |
| Max P (AVAPS maximum IPAP) | 6 to 40 cm H2O |
| Min P (AVAPS minimum IPAP) | 5 to 30 cm H2O |
| O2 (oxygen percent) | 21 to 100% |
| Ramp Time | Off, 5 to 45 min |
| Rate (respiratory rate) | 4 to 60 BPM |
| Rise (rise time) | 1 to 5 |
| Triggering and cycling | Auto-adaptive (Auto-Trak) or Auto-Trak Plus (optional) Trigger = normal, +1 to +7 Cycle = -2, -1, normal, +1 to +6 |
| AVAPS target tidal volume | 200 to 2000 ml BTPS |
| Max E | 0 to 100 cmH2O/l |
| Max R | 0 to 50 cmH2O/l/s |
| PPV% | 0 to 100% |
| Max P (PPV maximum pressure limit) | 5 to 40 cmH2O |
| Max V (PPV maximum volume limit) | 200 to 3500 ml |
| Patient Data | |
| Breath phase/trigger indicator | Spont, Timed, Exhale |
| PIP | 0 to 50 cm H2O |
| Patient/total leak | 0 to 200 l/min BTPS |
| Patient Trigger | 0 to 100% |
| Respiratory Rate | 0 to 90 BPM |
| Ti/Ttot | 0 to 91% |
| Minute volume | 0 to 99.0 l/min BTPS |
| Tidal volume | 0 to 3000 ml BTPS |
| General | |
| Oxygen inlet pressure range | 276 to 600 kPa (40 to 87 psig) |
| Weight with optional battery | 10.9 kg (24 lb) |
| Weight without optional battery | 10.0 kg (22 lb) |
| Dimensions | |
| Height | 33.7 cm (13.3 in) |
| Width | 39.4 cm (15.5 in) |
| Depth | 42.9 cm (16.5 in) |
| Electrical | |
| AC voltage | 100 to 240 VAC |
| AC frequency | 50 to 60 Hz |
| AC power | 300 VA |
| Battery operating time | 6 hours in normal conditions |
